Product Details:
|
| Product Name: | PCB Drying Oven | Temp Range (℃): | RT+5 ~300°C |
|---|---|---|---|
| Heating Rate: | About 10mins From RT To 100°C | Application: | Chemicals Processing,Plastics Processing,drying |
| Accu Racy: | ±1 | Power: | 1.6KW |
| Material: | Galvanized Steel Sheet | Voltage: | 110V/60Hz Or 220V/50Hz |
| Warranty: | 2 Years | After-sales Service Provided: | Video Technical Support |
| High Light: | Laboratory Sterilization Industrial Drying Oven,Industrial Drying Oven Constant Temperature |
||
Vertical Blowing Drying Oven Laboratory Sterilization lndustrial Drying Oven Oven Blowing Drying BoxConstant Temperature
2 years warranty
101: Suitable for routine testing for industrial and mining enterprises, basic laboratory and workshop,not recommended for continuous use
Rank:★★★
KH:Recommended to use for routine experiment and test , cost-effective.
Rank:★★★★
Drying oven is widely used in drying process, sterilization, constant temperature storage, heat treatment and other fields. It is the basic supporting equipment of laboratories, scientific research institutions, industrial and mining enterprise laboratories. This product is not suitable for the baking and drying of volatile flammable and explosive materials, which is easy to cause explosion.
101 series heating element adopts heating wire, so it is not suitable for samples with large water content. KH series (101 upgraded model) can be recommended, because it uses heating tube to heat, which is more durable than heating wire. KH series air duct is a three-sided circulating air outlet, which is more reasonable and more uniform than 101 single-sided air outlet.
Acquired CE safety certification, 2-year warranty.
101 introduction:
Two kinds of controller types: Pointer controller, LED PID controller.
shell is made of high quality cold-rolled steel with metallic paint spray.
low noise fans and air cycling duct.
two internal chamber materials:stainless steel and galvanized steel.
the spaces and quantity of shelves can be adjusted.
double tempered glass observation window in the door.
101: forced air circulation
202:natural air circulation
Optional accessories:
1,individual temperature limit
| Model |
Voltage (V) |
Temp range (℃) |
Accu racy (℃) |
Fluct uation (%) | Power (KW) | Inner size (mm)(H*W*D) |
Overall dimension (mm) (H*W*D) |
Packing size(mm) (H*W*D) |
Net weight(KG) |
Shiping weight (KG) |
| 101-0(AS) | 220 | RT+5 ~300 | ±1 | ±1 | 0.8~1.6 | 350*350*350 | 590*660*520 | 710*740*600 | 34.8 | 37.2 |
| 101-1(AS) | 0.8~1.6 | 450*450*350 | 690*760*520 | 810*840*600 | 41.5 | 45 | ||||
| 101-2(AS) | 1.6~2.4 | 550*550*450 | 790*870*640 | 910*950*720 | 60 | 64.5 | ||||
| 101-3(AS) | 2~3 | 750*600*500 | 1050*980*700 | 1270*1060*780 | 80 | 84.5 |
| 101-4(AS) | 380 | ±2 | 3~4.8 | 1000*800*800 | 1300*1210*1000 | 1420*1290*1080 | 162 | 168 | ||
| 101-5(AS) | 6 | 350*350*350 | 590*660*520 | 710*740*600 | 189 | 197 |
Notes
The modes with “A” is LED microcomputer controller.
The modes with “S” is stainless steel inner chamber.
